| ETIM Group: | Programmable logic controllers PLC |
| ETIM Class: | PLC CPU-module |
| Additional program memory possible: | false |
| Appendant operation agent (Ex ia): | false |
| Appendant operation agent (Ex ib): | false |
| Depth: | 75mm |
| Explosion safety category for dust: | None |
| Explosion safety category for gas: | ATEX gas-ex-protection, Cat. 3G |
| Front built-in possible: | false |
| Height: | 100mm |
| IO link master: | false |
| Long-Term Evolution (LTE): | – |
| Max. number of time switches: | – |
| Memory size: | 75kByte |
| Model: | Compact |
| Number of analogue inputs: | 2 |
| Number of analogue outputs: | 0 |
| Number of digital inputs: | 14 |
| Number of digital outputs: | 10 |
| Number of HW-interfaces industrial Ethernet: | 1 |
| Number of HW-interfaces other: | 0 |
| Number of HW-interfaces parallel: | 0 |
| Number of HW-interfaces RS-232: | 0 |
| Number of HW-interfaces RS-422: | 0 |
| Number of HW-interfaces RS-485: | 0 |
| Number of HW-interfaces USB: | 0 |
| Number of HW-interfaces Wireless: | 0 |
| Number of interfaces PROFINET: | 1 |
| Number of relay outputs: | 0 |
| Processing time (1K, binary operation): | 0.085ms |
| Rack-assembly possible: | false |
| Radio standard Bluetooth: | false |
| Radio standard GPRS: | false |
| Radio standard GSM: | false |
| Radio standard UMTS: | false |
| Radio standard Wi-Fi 802.11: | false |
| Rail mounting possible: | true |
| Redundancy: | false |
| Suitable for safety functions: | false |
| Supply voltage AC 50 Hz: | – – |
| Supply voltage AC 60 Hz: | – – |
| Supply voltage DC: | 20.4 – 28.8V |
| Supporting protocol for ASI: | true |
| Supporting protocol for AS-Interface Safety at Work: | false |
| Supporting protocol for CAN: | false |
| Supporting protocol for Data-Highway: | false |
| Supporting protocol for DeviceNet: | false |
| Supporting protocol for DeviceNet Safety: | false |
| Supporting protocol for DNP3: | – |
| Supporting protocol for EtherNet/IP: | false |
| Supporting protocol for Foundation Fieldbus: | false |
| Supporting protocol for IEC 60870: | – |
| Supporting protocol for IEC 61850 Ethernet: | – |
| Supporting protocol for INTERBUS: | false |
| Supporting protocol for INTERBUS-Safety: | false |
| Supporting protocol for KNX: | false |
| Supporting protocol for LON: | false |
| Supporting protocol for Modbus: | true |
| Supporting protocol for other bus systems: | true |
| Supporting protocol for PROFIBUS: | true |
| Supporting protocol for PROFINET CBA: | false |
| Supporting protocol for PROFINET IO: | true |
| Supporting protocol for PROFIsafe: | false |
| Supporting protocol for SafetyBUS p: | false |
| Supporting protocol for SERCOS: | false |
| Supporting protocol for SUCONET: | false |
| Supporting protocol for TCP/IP: | true |
| System accessory: | true |
| Type of memory: | RAM |
| Voltage type of supply voltage: | DC |
| Wall mounting/direct mounting: | true |
| Width: | 110mm |
| With display: | false |
| With optical interface: | false |
