Schneider Electric Altivar Process ATV630D75N4 adalah variable speed drive (VSD/VFD) 75 kW atau 100 HP yang dirancang untuk mengendalikan motor tiga fase pada tegangan suplai 380 hingga 480 VAC. Bagian dari seri Altivar Process ATV600, drive ini ditujukan untuk aplikasi process dan utilities dengan dukungan motor asynchronous maupun synchronous. ATV630D75N4 memiliki enclosure IP21 dan UL Type 1, sehingga sesuai untuk instalasi wall-mounted pada berbagai sistem otomasi industri.

ATV630D75N4 memiliki rating motor 75 kW / 100 HP untuk normal duty dan 55 kW / 75 HP untuk heavy duty. Pada normal duty, line current mencapai 131,3 A pada 380 V dan 112,7 A pada 480 V, sedangkan continuous output current mencapai 145 A pada switching frequency 2,5 kHz. Drive ini mendukung output frequency hingga 500 Hz, adjustable switching frequency 2–8 kHz, serta beberapa mode kontrol motor seperti constant torque, variable torque, dan optimized torque.

Schneider ATV630D75N4 dilengkapi berbagai fungsi untuk aplikasi process dan utilities, termasuk embedded power measurement and energy dashboard, process monitoring and control, Stop and Go function, asset monitoring and protection, serta drift monitoring. Untuk integrasi otomasi, unit menyediakan konektivitas Ethernet, Modbus serial dan Modbus TCP, dengan pilihan communication module seperti PROFINET, PROFIBUS DP V1, DeviceNet, EtherNet/IP, CANopen, dan modul I/O tambahan. Drive menggunakan forced-convection cooling dan dilengkapi fungsi keselamatan Safe Torque Off (STO) SIL 3.

Reviews

There are no reviews yet.

Be the first to review “Schneider ATV630 75kW/100HP 380 to 480V – ATV630D75N4”

Specification

Brand	Schneider Electric
Product Series	Altivar Process ATV600
Model / Part Number	ATV630D75N4
Product Type	Variable Speed Drive (VSD/VFD)
Device Short Name	ATV630
Product Application	Process and Utilities
Variant	Standard Version
Motor Type	Asynchronous and Synchronous Motors
Motor Power – Normal Duty	75 kW / 100 HP
Motor Power – Heavy Duty	55 kW / 75 HP
Rated Supply Voltage	380–480 VAC, 3-phase
Supply Voltage Tolerance	-15% to +10%
Supply Frequency	50–60 Hz
Network Frequency Tolerance	±5%
Line Current – Normal Duty	131.3 A at 380 V / 112.7 A at 480 V
Line Current – Heavy Duty	98.9 A at 380 V / 86.9 A at 480 V
Continuous Output Current – Normal Duty	145 A at 2.5 kHz
Continuous Output Current – Heavy Duty	106 A at 2.5 kHz
Maximum Transient Current – Normal Duty	159.5 A for 60 seconds
Maximum Transient Current – Heavy Duty	159 A for 60 seconds
Output Frequency	0.0001–500 Hz
Nominal Switching Frequency	2.5 kHz
Adjustable Switching Frequency	2–8 kHz
Motor Control	Constant Torque, Variable Torque, Optimized Torque Mode
Safety Function	Safe Torque Off (STO), SIL 3
Cooling Type	Forced Convection
Mounting	Wall Mount
Protection Rating	IP21
UL Protection Type	UL Type 1, UL 508C
EMC Filter	Integrated EN/IEC 61800-3 Category C3, 150 m
Communication	Ethernet, Modbus Serial, Modbus TCP
Optional Communication Modules	PROFINET, PROFIBUS DP V1, DeviceNet, EtherNet/IP, Modbus TCP, CANopen
Communication Ports	3 built-in RJ45 communication ports
Discrete Input Function	16 Preset Speeds
Brake Chopper	Not integrated
Prospective Line Short-Circuit Current	50 kA
Maximum Output Voltage	480 VAC
Operating Mode	4-quadrant operation not supported
Energy Management	Embedded power measurement and energy dashboard
Process Functions	Embedded process monitoring and control
Energy Saving Function	Stop and Go function
Protection / Monitoring	Asset monitoring and protection, drift monitoring
Application Areas	Water and wastewater, mining, minerals and metals, oil and gas, food and beverage, process industries
