Schneider Electric RM35JA32MR Current Control Relay 0.15A–15A

Schneider Electric RM35JA32MR adalah current control relay dari Harmony Control Relays / Zelio Control yang dirancang untuk memonitor arus listrik AC maupun DC pada rangkaian industri. Relay ini memiliki rentang pengukuran 150 mA hingga 15 A pada 50/60 Hz, dengan tiga pilihan terminal pengukuran yaitu 0.15–1.5 A melalui E1-M, 0.5–5 A melalui E2-M, dan 1.5–15 A melalui E3-M. RM35JA32MR mendukung fungsi deteksi overcurrent dan undercurrent, termasuk mode window untuk pemantauan batas arus.

Schneider RM35JA32MR menggunakan 2 C/O (changeover) relay outputs dengan nominal output current hingga 8 A dan maximum switching voltage 250 V AC. Power supply relay berada pada rentang 24–240 V AC/DC, 50/60 Hz, dengan supply voltage limit 20.4–264 V AC/DC. Time delay dapat diatur dari 0.1 hingga 30 detik, sementara threshold dapat disesuaikan pada 10–100% untuk membantu menyesuaikan relay dengan kebutuhan proteksi dan monitoring aplikasi.

Dengan housing modular berukuran 35 mm, RM35JA32MR cocok dipasang pada 35 mm DIN rail di dalam panel kontrol. Relay menggunakan screw terminals dan dilengkapi indikator LED untuk status power dan relay. Schneider Electric juga mencantumkan aplikasi untuk berbagai kebutuhan industri seperti hoisting, packaging, lift, textile, pumping, dan water applications. Model RM35JA32MR tercatat discontinued oleh Schneider Electric sejak 1 Desember 2024, sehingga ketersediaan stok perlu diperiksa sebelum pengadaan.

Reviews

There are no reviews yet.

Be the first to review “Schneider RM35JA32MR”

Specification

Specification	Details
Brand	Schneider Electric
Product Range	Harmony Control Relays / Zelio Control
Product Type	Current Control Relay
Model / Reference	RM35JA32MR
Relay Name	RM35JA
Monitored Parameters	Overcurrent and Undercurrent
Monitoring Mode	Overcurrent or Undercurrent Detection; Overcurrent or Undercurrent Window Mode
Measurement Range	150 mA…15 A AC/DC, 50/60 Hz
E1-M Measurement Range	0.15…1.5 A
E2-M Measurement Range	0.5…5 A
E3-M Measurement Range	1.5…15 A
Rated Supply Voltage	24…240 V AC/DC, 50/60 Hz
Supply Voltage Limits	20.4…264 V AC/DC
Output Contacts	2 C/O (Changeover)
Nominal Output Current	8 A
Maximum Switching Current	8 A AC
Maximum Switching Voltage	250 V AC
Switching Capacity	2000 VA
Minimum Switching Current	10 mA at 5 V DC
Time Delay	Adjustable 0.1…30 s
Power-Up Delay	0.3 s
Hysteresis	5…50% adjustable for overcurrent/undercurrent detection; 3% fixed of full scale for window mode
Threshold Setting	10…100%
Switching Threshold Accuracy	±10% of full scale
Measurement Cycle	100 ms, true RMS measurement
Repeat Accuracy	±0.5% for input and measurement circuit; ±2% for time delay
Reset Time	≤1500 ms at maximum voltage
Power Consumption	3.5 VA AC / 1.5 W DC
Connections	Screw terminals
Mounting	35 mm DIN Rail, EN/IEC 60715
Mounting Position	Any position
Width	35 mm
Weight	Approx. 0.12 kg
Insulation Resistance	>100 MΩ at 500 V DC
Overvoltage Category	III
Electrical Durability	100,000 cycles
Mechanical Durability	10,000,000 cycles
Status Indicators	Green LED: Power ON; Yellow LED: Relay ON
Applications	Hoisting, packaging, lifts, textile, pumping, water and industrial automation
Status	Discontinued on 1 December 2024
EAN	3606480792304
